Abington – Non Electric
<span class="woocommerce-Price-amount amount"><bdi><span class="woocommerce-Price-currencySymbol">£</span>1,600.00</bdi></span>
£1,600.00
Embrace a contemporary interpretation of timeless elegance. Crafted and designed in Cambridge, this sophisticated town bike seamlessly merges classic style with cutting-edge engineering.
The Abington is a sleek town bike designed and made in Cambridge:
The Abington comes with the following as standard:
- 8 Speed Shimano Alfine
- Custom-drawn Reynolds Technology steel tubing
- Standard frame colour options
- Gates Carbon Belt Drive
- Machined stainless-steel dropouts
- Schwalbe Marathon Plus 650b x 38 tyres
- 5-year warranty on the frame
- 1st service free (book within 8 weeks)
To view more accessories including mudguards for the Abington bike click here: Abington Accessories
If the configuration you would like is not listed please submit your enquiry via the ‘Contact Us‘ page or call us on 01223 893 290.
Bike Specification
| Specification | |
| Wheel Size | 650B – 27.5 |
| Frame | Custom-drawn Reynolds Technology steel tubing 631 |
| Fork | ARCC Custom Forks |
| Front Suspension | N/A |
| Rear Suspension | N/A |
| Separability/Folding | N/A |
| Frame Finish | Powder Coat |
| Mudguards | Optional Extra – SKS Full Mudguards |
| Headset | 1 1/8” |
| Front hub | Shimano Deore 36h |
| Rear hub | Dependant on selection – Shimano Alfine/ Rohloff 36h |
| Spokes | 36 |
| Rims | Double Wall Rim 36h |
| Tyres | Schwalbe 27.5/650B Marathon Plus |
| Tubes | Schwalbe |
| Crank set | Gates |
| Bottom bracket | Thun Square Taper |
| Brake levers | Tektro hydraulic with integrated quick connection power cut off sensors |
| Brakes | Tektro Hydraulic Disc Brakes: 160mm front, 140mm rear. |
| Gear lever | Dependant on Selection – Shimano Alfine/Rohloff |
| Cassette/Sprocket | Gates 22T |
| Chain/Belt | Gates Carbon Belt Drive |
| Pedals | Components VP607 alloy/rubber tread |
| Seat post | Alloy 27.2mm 400mm |
| Saddle | Brooks C19 Cambium |
| Handlebar stem | 6 Degree (80mm S/M) (100mm M/L or XL) |
| Handlebar | Alloy Low Riser |
| Handlebar Grips | Ergo Grips |
| Lighting/Reflectors | Reflectors front and rear |
| Seat Post Clamp | Alloy Seat Clamp |
| Frame Size | S/M – M/L or XL |
| Weight | From 10.5kg |
| Gearing | Dependant on selection – Shimano Alfine/Rohloff |
Free Delivery
Please note that we only ship to addresses in the United Kingdom and are unable to ship to PO Boxes, British Forces Post Office (BFPO), Channel Islands or Isle of Man. Despatched next working day if ordered before 12 noon.
Please note that we only ship to addresses in the United Kingdom and are unable to ship to PO Boxes, British Forces Post Office (BFPO), Channel Islands or Isle of Man. We aim to complete your order ready for despatch within 10 working days of sending the order acknowledgment.
Description
The Abington is a sleek town bike designed and made in Cambridge:
The Abington comes with the following as standard:
- 8 Speed Shimano Alfine
- Custom-drawn Reynolds Technology steel tubing
- Standard frame colour options
- Gates Carbon Belt Drive
- Machined stainless-steel dropouts
- Schwalbe Marathon Plus 650b x 38 tyres
- 5-year warranty on the frame
- 1st service free (book within 8 weeks)
To view more accessories including mudguards for the Abington bike click here: Abington Accessories
If the configuration you would like is not listed please submit your enquiry via the ‘Contact Us‘ page or call us on 01223 893 290.
Bike Specification
Bike Specification
| Specification | |
| Wheel Size | 650B – 27.5 |
| Frame | Custom-drawn Reynolds Technology steel tubing 631 |
| Fork | ARCC Custom Forks |
| Front Suspension | N/A |
| Rear Suspension | N/A |
| Separability/Folding | N/A |
| Frame Finish | Powder Coat |
| Mudguards | Optional Extra – SKS Full Mudguards |
| Headset | 1 1/8” |
| Front hub | Shimano Deore 36h |
| Rear hub | Dependant on selection – Shimano Alfine/ Rohloff 36h |
| Spokes | 36 |
| Rims | Double Wall Rim 36h |
| Tyres | Schwalbe 27.5/650B Marathon Plus |
| Tubes | Schwalbe |
| Crank set | Gates |
| Bottom bracket | Thun Square Taper |
| Brake levers | Tektro hydraulic with integrated quick connection power cut off sensors |
| Brakes | Tektro Hydraulic Disc Brakes: 160mm front, 140mm rear. |
| Gear lever | Dependant on Selection – Shimano Alfine/Rohloff |
| Cassette/Sprocket | Gates 22T |
| Chain/Belt | Gates Carbon Belt Drive |
| Pedals | Components VP607 alloy/rubber tread |
| Seat post | Alloy 27.2mm 400mm |
| Saddle | Brooks C19 Cambium |
| Handlebar stem | 6 Degree (80mm S/M) (100mm M/L or XL) |
| Handlebar | Alloy Low Riser |
| Handlebar Grips | Ergo Grips |
| Lighting/Reflectors | Reflectors front and rear |
| Seat Post Clamp | Alloy Seat Clamp |
| Frame Size | S/M – M/L or XL |
| Weight | From 10.5kg |
| Gearing | Dependant on selection – Shimano Alfine/Rohloff |
Reviews (0)
Reviews
There are no reviews yet.
Shipping & Delivery
Free Delivery
Please note that we only ship to addresses in the United Kingdom and are unable to ship to PO Boxes, British Forces Post Office (BFPO), Channel Islands or Isle of Man. Despatched next working day if ordered before 12 noon.
Please note that we only ship to addresses in the United Kingdom and are unable to ship to PO Boxes, British Forces Post Office (BFPO), Channel Islands or Isle of Man. We aim to complete your order ready for despatch within 10 working days of sending the order acknowledgment.
Intelligent Drive System Specifications
- e-bike Classification:
- Pedelec (road-legal)
- Motor:
- Bafang/ Aikema: Brushless 250W 36V DC front wheel drive.
- IP Rating: 65.
- Battery:
- Bosch Li-ion 36V 4Ah (144 Wh).
- Bosch Li-ion 36V 6Ah (216 Wh) optional.
- Mains Charger:
- Bosch GAL3860 CV fast charger.
- Battery Charge Time:
- 4Ah: 25mins to 80%, 35mins to 100%
- 6Ah: 35mins to 80%, 55mins to 100%
- Control Pod:
- CNC-machined Peraluman 470 aluminium grade 5083/AlMg 4.5Mn. Black anodised finish.
- Control Pod USB Interfaces:
- 1 x USBC 2.0 charging/data port 5V, 1500mA.
- 1 x USBC 2.0 charging/data port 5V, 500mA.
- 1 x USBC 2.0 charging port 5V, 500mA.
- Bottom Bracket:
- NCTE torque and cadence sensor (square taper)
- Brake Switch:
- Safety cut-off switches, front and rear.
- Assisted Range:
- 4Ah up to 35km depending on riding style.
- 6Ah up to 52km depending on riding style.
- Maximum Assisted Speed:
- Power assist is limited to 15.5mph/25kmh
- System Weight:
- 2.6kg system only
- 3.9kg incl. 4Ah 36v battery.
- Assistance Remote Controller:
- ARCC Bluetooth remote Controller (Handlebar mounted) CNC-machined.
- iOS app compatible (Free APP)
- System Status Indicators:
- 2 x tri-colour LED’s.
- Spare Battery Holder:
- Optional spare battery holder – CNC Machined Peraluman 470 aluminium grade 5083/AlMg 4.5Mn anodised Black/Red.
